LW1401
Portable Cut-off, 355 mm, 2200 W
A 2 200 W cut-off saw for accurate, safe and quick cutting of metal. A carry handle for easy transport and a well-designed spark guide for added safety
Technologies and functions
double-insulation
Double Insulation
Advantages
- Powerful 2,200W motor delivers 3,800 RPM for superior performance and durability
- Large cutting capacity
- Cuts up to 127 mm (5") round and 115mm (4-1/2") x 130mm (5-1/8") rectangular
- Replacement of Abrasive cut-off wheel and adjustment of Guide plate can be done without any tools. (for LW1400 only)
- Large spark guard minimizes backward spark scattering
- Quick release vise for secure stock retention and fast repeated cut offs
- D-shape handle for user comfort
- Carry handle for easy transport to job site
- Pin type saw head locking device for storage and transport (for LW1400 only)
- Chain type saw head locking device for storage and transport (for LW1401 only)
- Shaft lock for easy replacement of abrasive cut-off wheel
- Lock-off button minimizes accidental start up. (country-specific)
- Double insulated for operator safety
Specifications
Capacity, mm
355
Type of motor
Brush
No load speed, rpm
3'800
continuous rating input
2'200
Power supply cord, m
3
Mounting diameter, mm
25.4
Глубина реза 0°_ENG
Round: 127 mm
Глубина реза 45°_ENG
Round: 127 mm / Rectangular: 115 x 103 mm / Square: 106 x 106 mm / Triangular: 100 x 100 x 10 mm
Глубина реза 90°_ENG
Rectangular: 115, 102, 70 x 233, 194, 130 mm / Square: 119 x 119 mm / Triangular: 137 x 137 x 10 mm
Двойная изоляция
Net Weight, kg
18.3
Vibration level, m/s²
2.5
Vibration K factor, m/s²
1.5
Sound pressure level, dB
102
Sound power level, dB
110
Noise K factor, dB
3
Carbon brush
203
Depth, mm
500
Width, mm
295
Height, mm
640
Code EAN
0088381807920
Packaged Width, mm
370
Packaged Depth, mm
470
Packaged Height, mm
560
Weight (package), kg
21.88
HS code
8461509009
