DCG180Z
Cordless Caulking Gun 18V LXT®
Battery and charger are sold separately
A professional-use caulking gun for bulk caulk and adhesives and cartridges. A variable speed dial for adjusting the flow rate. A handy trigger for adjusting the flow rate to suit the application. This light and compact tool is an ideal choice for caulking and gluing.
Technologies and functions
variable-speed
Variable Speed
built-in-job-light
Built-in Job Light
Advantages
- Delivers an industry-leading 5,000 N (1,100 lbs) of dispensing force to work with the highest viscosity adhesives and sealants
- 5 speed dial optimizes flow rate from 0 - 28 mm/sec. (0 - 66 IPM)
- Variable speed trigger allows user to match the speed to the application
- 360° rotatable cartridge holder fits 800 mL, 600 ml and 300 ml cartridges
- Drip-reduction feature automatically relieves pressure on the material when trigger is released to minimize unintentional dispensing
- Overload indicator light notifies the operator when tool is nearly overloaded to minimize breakage of the sealant cartridge
- Compact and lightweight design
- Built-in LED light with afterglow illuminates the work area
- Soft grip handle provides increased comfort and control on the job
- To minimize the switch trigger from accidentally pulled, the trigger-lock button is provided
- Battery protection circuit protects against overloading, over-discharging and over-heating
Specifications
Max dispersing force, N
5'000
Holder size, ml
300 / 600 / 800
Type of motor
Brush
Platform
18V LXT®
Type of battery
Li-Ion
Voltage, V
18
Charger
Compatible batteries
18 V: 6.0 Ah / 5.0 Ah / 4.0 Ah / 3.0 Ah / 2.0 Ah / 1.5 Ah / 1.3 Ah
Variable speed
Built-in job light
Continuous rating output, W
150
Stroke length with 300 ml holder, mm
214
Stroke length with 600 ml holder, mm
350
No load speed, mm
0 - 28
Net weight, kg
2.1
Sound pressure level, dB
70
Noise K factor, dB
3
Vibration level, m/s²
2.5
Vibration K factor, m/s²
1.5
Depth, mm
404
Width, mm
108
Height, mm
281
Code EAN
0088381658645
Packaged Width, mm
190
Packaged Depth, mm
140
Packaged Height, mm
420
Weight (package), kg
1.5
HS code
8467292000
